Telemecanique Sensors – XS8C4A4PCP20 Inductive Proximity Sensor
Product Overview
Model: XS8C4A4PCP20
Series / Type: XS Series – General-purpose inductive proximity sensor
Housing Design: Rectangular, 40 × 40 × 117 mm (standard format)
Sensing Distance: 40 mm (nominal)
Supply Voltage: 12–48 V DC, with reverse polarity protection
Output Type: PNP, 1 Normally Open (NO) + 1 Normally Closed (NC)
Maximum Switching Current: 200 mA, with short-circuit and overload protection
Protection Rating: IP67 (IEC 60529), suitable for harsh environments (IP65 / IP69K rated)
Safety Ratings: SIL 2 (IEC 61508), Performance Level d (ISO 13849-1)
PFHd ≈ 7.4 × 10⁻⁸ /h, MTTFd ≈ 1546 years
Operating Temperature Range: -25 °C to +70 °C
Certifications: CE marked, compliant with international safety standards
High-Reliability Square Metal Sensor with 40 mm Sensing Distance for Demanding Industrial Environments
Features & Advantages
Rugged Square Metal Housing
The XS8C4A4PCP20 features a robust 40 × 40 × 117 mm rectangular housing made of PBT with reinforced construction. The square form provides mechanical strength, stability, and flexible mounting options in industrial installations.
Extended 40 mm Sensing Distance
Offers a large nominal sensing range of 40 mm, enabling reliable metal object detection in a wider range of setups.
High Environmental Protection
IP67 and IP69K ratings ensure resistance to dust, water jets, and high-pressure washdown, suitable for harsh or outdoor conditions.
Advanced Safety Performance
Certified for SIL 2 and Performance Level d (PL d), with MTTFd exceeding 1500 years. Ideal for machine safety circuits and high-reliability position detection applications.
Flexible Electrical Interface
Dual PNP outputs (NO + NC) with 200 mA switching capability and integrated protection circuits simplify integration into modern control systems.
Easy Installation
Standardized rectangular body and M20 x 1.5 cable entry allow quick, secure, and flexible mounting, even in space-limited areas.
Typical Applications
Position and presence detection of metal parts in automated production lines
Material handling systems and transfer machinery for proximity or limit detection
Applications in dusty, wet, or outdoor environments such as cleaning systems and mobile equipment
Machine safety systems requiring high-reliability sensors for safety circuits
Large industrial equipment requiring long sensing distance and robust rectangular housing (e.g., metallurgy, mining, construction machinery)
User Requirement |
Reliability & Stability |
Detection Range & Flexibility |
Environmental Resistance |
Ease of Installation |
Safety Integration |
XS8C4A4PCP20 Advantage |
High safety ratings (SIL2 / PLd), short-circuit protection, and 200 mA output ensure dependable operation. |
40 mm sensing distance offers superior reach and installation freedom. |
IP67/IP69K protection and -25…+70 °C temperature range enable operation in harsh conditions. |
Standard 40×40×117 mm rectangular format with M20 cable entry simplifies integration. |
Dual NO+NC PNP outputs and certified safety compliance make it ideal for machine protection systems. |
Summary
The Telemecanique Sensors XS8C4A4PCP20 is a high-performance inductive proximity sensor engineered for industrial automation and safety applications. Combining a large 40 mm sensing distance, rectangular form factor, and IP69K-rated housing, it delivers durability, precision, and reliability in demanding environments. With SIL2/PLd certification, advanced protection features, and easy installation, the XS8C4A4PCP20 ensures consistent performance and long service life for OEMs, integrators, and maintenance engineers.
